| 型号 | 焦距 | 视野范围FOV | 倍率范围 | 工作距离 | |||||
| 16k5μm | 16k3.5μm | 8k7μm | 8k5μm | 4k7μm | 4k5μm | ||||
| DHJ2540A-0.03X | 25 | 560-1867 | 400-1333 | 0.015-0.05 | 520-1740 | ||||
| DHJ3528A-01X | 35 | 187-560 | 133-400 | 0.05-0.15 | 240-700 | ||||
| DHJ4032A-0.1X | 40 | 285-2850 | 133-1000 | 93-700 | 67-500 | 0.02-0.2 | 226-2100 | ||
| DHJ5040A-0.1X | 50 | 380-814 | 380-814 | 266-571 | 186-400 | 133-285 | 0.07-0.15 | 355-735 | |
| DHJ6040A-0.1X | 60 | 311-1867 | 222-1333 | 155-933 | 111-667 | 0.03-0.18 | 370-2050 | ||
| DHJ8040A-0.5X | 80 | 91-152 | 91-152 | 64-106 | 45-74 | 32-53 | 0.375-0.625 | 188-273 | |
| DHJ1620A | 146 | 32-46 | 22-32 | 22-32 | 1.75-2.5 | 154-179 | |||
